224-310KW广西顶博发电机组制造:康明斯发电用发动机可靠性高：高强度合金铸造缸体、可锻铸铁(FCD) 活塞，刚性更好，降低振动和噪声，提高了发动机适应更高的爆发压力。

High reliability: intensified alloy casting cylinder and Ferrous Cast Ductile (FCD) piston provide engine a better rigidity performance and lower vibration & noise, and also make the engine adapt to higher explosion pressure.

康明斯火力发电用启因素柴油利用效率性好: 先进典型的柴油操作制定，独具的STC、ESTC 分级制度操作制定，特别制定的汽缸顶部焚烧室，高压力压喷射柴油，足够做雾化，焚烧足够。

Good fuel economy: Advanced fuel control system, unique STC, ESTC step control system, specilly-designed piston topchamber and high pressure fuel injection lead to an excellent fuel consumption rate and emission performance of engine.

康明斯风能发电用热车机瞬态的性能高品质: 完美无瑕的热车机综合方案，做好康明斯的难忘的EFC装置，有效控制计算精性高，为了响应周期快。

Excellent transient performance: perfect overall engine design with unique Cummins EFC system, high precision on control and quick response time.

康明斯来发电用打着机升工作电压高: 综合设计的概念紧密.外观搭建合理有效，运营有序。High lift power: Integrated and compact design, reasonable layout and smooth operation.

电喷门焊机 QSNT. QSK19. QSK38. QSK50满意全球非道路上三阶段中及中美洲Tier2. Tier 3排放标准法律规范规范要求。

Electric fuel injection engines (QSNT,QSK19,QSK38,QSK50) meet the Tier3 emission regulations for China non-road vehicles and Tier2 & Tier3 emission regulations of North America.

零备品备件能得性好， 打着机程序运行及运营维护养护等便捷，料工费低。Good availbility of spare parts, smooth engine operation, convenient engine maintenance and low cost.

发动机规格Engine Specifications

功效使用范围 Power Range   224-310KW连接结构 Type   直列/六缸/四冲程/四气门  In-ine/6-Cylinder/4-Stroke/4-Valve缸径x冲程 BoreX Stroke  125X 147mm排量 Displacement   11L外观简约时尚技术参数 Dimension  长X宽X高(LXWX H) 1360 x 833X 1068 mm净效率 Dry Weight   940kg

224-310KW康明斯发电量用汽车发主观因素的显著特点：比热容小， 压解比较高， 格栅板空气中加水，易重启，运动车载电子开关电源的常选。Compact size, high compression ratio, gile heated by air, easy for start-up, the first option of mobile vehicle power supply.

推荐机型Engine Models Recommended

打火机款型	所用马力(kW)Prime Power	预备输出kW)Standby Power
MTA11-G2	224	246
MTAA11-G3	282	310
